Kingsun PH10 Outdoor Advertising LED display
Features

1.High Brightness: Viewers can see the images clearly at a long distance in sharp sunlight because of using high brightness LED lamps
2.Long lifetime: Adopting high quality LED lamps as core material and patent PCB design for the screen, it essentially ensures long lifetime of the product.
3.Stable performance: We make a special treatment of anti-electromagnetic wave and adopt distribution scan and modular design for the screen and it works more reliable and stable.
4.Exquisite images: Nonlinearity correction technology makes the images exquisite and clear, video images vivid and fidelity.
5.Excellent flatness: Precision design of module frame parts controls the deviation of neighbouring modules within 0.1mm and it has an excellent flatness without mosaic.
6.High contrast: Consistent deep black and patent masks make the contrast higher and the color fresher.
7.Easy installation: Modular design makes the installation and maintenance easier.
8.Good material: Adopting same levels of imported LED chips from Taiwan, USA or Japan, high quality driving IC, low noise power supply, which can guarantee the screen work smooth in the environment of -40℃~60℃.
9.Multiple formats: Customers can choose any one of display formats for the screen, it can supports TXT, graphic, picture, animation and video programs.
10.Lacquer coating: Lacquer coasting can protect the PCB and relevant components from erosion of environment, it has the good resistance performance of low and high temperature, and excellent features of insulation, moisture proof, anti-creeping, dustproof, anti-corrosion.
11.High shockproof performance: The cabinets must be tested for shockproof performance before shipment to avoid poor contact because of loose of screws and disconnection of cables after long line-haul.
12.High waterproof performance: The cabinet must be treated for waterproof performance during production, and its front and back can be fully waterproof and it can work smoothly in outdoor all-weather.

Application

PH10 outdoor full color advertising LED display could be used in outdoor environment such as airport, highway, cultural or relax square, commercial walking street, residential sub-district, downtown, with various real-time signal sources and the speciality of waterproof, dustproof, anti-static , its purpose is to propagandize outdoor advertising or play the important news or events or TV program etc.

Specification KINGSUN PH10 Full Color Outdoor LED Display
LED lights DIP346
Pixel Pitch 10mm
Pixel Resolution 10000dots/㎡
Pixel Composing 1R1G1B
Module Dimension 160mm*160mm
Module Graphic Definition 16dots*16dots
Cabinet Dimension(W*H) 960mm*960mm*150mm(other sizes are customizable)
Cabinet Graphic Definition 96dots*96dots
Single Cabinet Weight 60kg/㎡
Bbest Viewing Angle 10~150m
Horizontal Viewing Angle  120°
Vertical Viewing Angle 60°
Average Power Consumption 280W/㎡
Maximum Power Consumption ≤700W/㎡
Graphic card DVI
Control Method synchronization
LED Driver constant current
Scan mode 1/4 scan
Frame Changing Frequency ≥60Hz
Refresh Rate ≥300Hz
Brightness ≥8000cd/㎡
Ingress Protection (Front/Rear)  IP65/IP54
Operation Temperature -20℃~50℃
Operation Humidity  10%~95%
Input Voltage AC220V/110V±15%  47-64Hz
Gray Scale 4096
Brightness Adjustment 256 level
System Operating Platform WINXP、WIN2000、WIN98 etc
Support Mode DVI、VGA、S-Video、RGBHV、COMPOSITION
Control System DVI graphic card+control card(gigabyte)+optical fibre transmission(option)
NTBF ≥50000 hours
Life Time 100000 hours
